GraphDetailTool

The GraphDetailTool is a complete UI wrapper around VisNetwork that adds node detail visualization, JSON editing, and multi-node selection capabilities.

Overview

GraphDetailTool composes VisNetwork and JsonEditor into a full graph editing workspace:

        graph LR
    subgraph gdt [" GraphDetailTool "]
        controls(["Edit Controls"])
        graph(["VisNetwork"])
        details(["Detail Panel"])
    end

    controls --> graph
    graph -- "click/select" --> details
    details -- "edit" --> graph

    classDef controlNode fill:#8b7355,stroke:#6b5840,color:#ffffff
    classDef graphNode fill:#0d7377,stroke:#095c5f,color:#ffffff
    classDef detailNode fill:#6366f1,stroke:#4f46e5,color:#ffffff

    class controls controlNode
    class graph graphNode
    class details detailNode


Features

• Edit mode controls: Toggle between view, add node, and add edge modes

• Node detail panel: Click a node to see its properties in a JSON editor

• Content visualization: Automatic rendering based on node data type:

  • Images (PNG, JPG, SVG)

  • CSV data (interactive table + Plotly charts)

  • PDF documents

  • Plain text

• Multi-node selection: Select multiple nodes to see a comparison table with bulk editing

• Drag position tracking: Node positions are automatically updated on drag

Usage

from panelini.panels.visnetwork import GraphDetailTool

nodes = [
    {"id": 2, "label": "Data Node", "csv_data": "col1,col2\n1,2\n3,4"},
    {"id": 3, "label": "Text Node", "text_content": "Hello World"},
]

edges = [
    {"from": 1, "to": 2},
    {"from": 2, "to": 3},
]

tool = GraphDetailTool(nodes=nodes, edges=edges)

# Access the underlying VisNetwork
tool.visnetwork.add_node({"id": 4, "label": "New"})

# The tool provides a complete Panel layout
tool.layout  # Use this in your Panel app

Detail Panel Tabs

When a node is clicked, the detail panel shows two tabs:

1. Visualization: Renders the node’s content based on its data type

2. Details: Shows all node properties in a JsonEditor for direct editing

Changes made in the JSON editor are automatically synced back to the graph.

API Reference

See the full API documentation: panelini.panels.visnetwork.graph_detail_tool.GraphDetailTool
